Control Board
The Control Board offers several features: you can easily set the starting address, run the pre-programmed
program or select a DMX channel mode.
The main menu is accessed by pressing Menu. Browse through the menu by pressing Up or Down. Press
Enter in order to select the desired menu. You can change the selection by pressing Up or Down. Press
Enter in order to confirm. You can leave every mode by pressing Menu. The functions provided are listed in
the following sections.
If you press and hold Up or Down, the values change faster. The device has an automatic storage for all
settings. When you switch the device off and on again, it will operate with the previously set values.
Default settings in bold
MAIN level
Menu level
YES/NO
Def.Set
DMX Addr
001-512
3 CH, 4 CH, 6CH,
DMX Chan
8CH, 11CH
OFF/Dim1/Dim2/
Dimmer
Dim3/Dim4
Master/Slave
Mast/Slav
Red – 000 - 255
Color Set
Green – 000 - 255
Blue – 000 - 255
White – 000 - 255
R – R+G+B+W
Col Mac
Description
Reset to factory settings
DMX address setting
Setting DMX channel mode
Dimmer speed (step response)
OFF: Response characteristics of LEDs
Dim1: Response characteristics of halogen lamps, fast
Dim2: Response characteristics of halogen lamps, less fast
Dim3: Response characteristics of halogen lamps, middle
Dim4: Response characteristics of halogen lamps, slow
Master/Slave mode
Dimmer intensity of the LED colors /
stepless RGBW color mixture 000 – 255 (increasing)
Dimmer intensity red
Dimmer intensity green
Dimmer intensity blue
Dimmer intensity white
Preset colors
R
G
B
W
R+G
25/32
R+B
R+G+B
R+W
R+B+W
G+B
G+B+W
G+W
R+G+W
B+W
R+G+B+W
00142487, Version 1.0
