FAFREES F-100 Bedienungsanleitung Seite 7

Product
Features
Remarks: electric quantity, load, tyre pressure, pavement environment, chain and
axle lubrication degree, etc. will affect the maximum speed; driving habits,
temperature, load, tyre pressure, pavement environment and other factors will
affect the endurance mileage.
Operating Your New e-Bike
1. Charging: Referring to Figure 1, open the plastic cover on the right side of the
frame, and you can see the charging hole; connect the charger to start charging;
when the battery capacity is displayed to be full, and the charger indicator light
changes from red to green, it means the battery is fully charged. You may charge
your battery while it is mounted on the e-bike, or after it has been removed from the
e-bike.
2. Turn on/off: Referring to Figure 2, press and hold the power button to turn on/off
the power.
3. Headlight: Referring to Figure 2, press the button on the right to turn on/off the
headlight.
4. PAS mode: You must turn on the battery to use the e-bike in pedal-assisted mode.
power assist is triggered when you pedal forward, and power assist stops when you
stop pedaling, sometime would be delay. If no power is needed, turn off the power
of the battery.
5. Hand Throttle Control: You do not need to pedal the e-bike if you use the hand
throttle. You control the throttle by twisting it from its resting position, the farther
the throttle switch is from its resting position, the more power is delivered to the
motor to accelerate the e-bike.
6. PAS Speed change: Referring to Figure 2, press the "+" and "-" button to change
the current output of the controller thus change the speed.
7. Gear shift: Referring to Figure 3, turn the speed change shifter while the vehicle is
moving to achieve speed change from gear 1 to gear 7 and vise versa.
Under voltage protection value
Over current protection value
Charging time
Display
Front light
Braking method
Controller
Transmission
Tyre type
39V
15A
5 hours
Multi-function LCD display
Yes
Front and rear mechanical disc
brakes
3 Shift intelligent control system
SHIMANO 7 speed
Pneumatic tyre
