All manuals and user guides at all-guides.com Sicherheitshinweise Bitte lesen Sie diese Hinweise vor dem ersten Gebrauch sorgfältig durch. Allgemeine Hinweise Bedienen Sie das Gerät nicht beim Lenken eines motorbetriebenen Fahrzeugs z.B. am Steuer eines Autos oder auf dem Fahrrad. Stellen Sie das Gerät niemals auf einen instabilen Untergrund.
All manuals and user guides at all-guides.com Sicherheitshinweise Umgebungsbedingungen Halten Sie Magnetkarten, z.B. Kredit- oder EC-Karten sowie Uhren mit Unruh vom Gerät fern, um Schäden durch den Magneten des einge- bauten Lautsprechers zu vermeiden. Vermeiden Sie starke mechanische Beanspruchungen des Gerätes. Schützen Sie es vor Vibrationen, harten Stößen, lassen Sie es nicht fallen und schütteln Sie es nicht.
All manuals and user guides at all-guides.com Sicherheitshinweise Sammelstellen Batterien zurück. Störungen Sollte ein Gegenstand oder Flüssigkeit in das Gerät gelangen, entfer- nen Sie die Batterien. Lassen Sie das Gerät von einer autorisierten Fachkraft überprüfen, bevor Sie es weiter verwenden. Wir empfehlen Ihnen, sich an unser Service-Center zu wenden.
8 Kanäle im 446 MHz PMR-Band Externer Anschluss für Kopfhörer- und Sprechgarnitur Eingebauter Li-Ionen Akku Ladebuchse für Steckerladegerät Abmessungen:120 x 42 x 18mm Lieferumfang: 2 x WT200 (inkl. NiMH-Akku), 1 x Steckermetzteil, 1 x Doppelstand- lader,2 x Ohrhörersprechgarnituren, Bedienungsanleitung - 6 -...
All manuals and user guides at all-guides.com Gerätebeschreibung Geräteansicht Antenne Headset-Buchse Display PTT Taste Ruf-Taste Ein/Aus-Taste Menü Taste Aufwärts-/ Abwärts-Taste Mikrofon Lautsprecher Ladekontakte (auf der Rückseite) - 7 -...
All manuals and user guides at all-guides.com Gerätebeschreibung Displayansicht Kanalanzeige Scan Anzeige Pilotton (CTCSS) VOX Betrieb Dual-Watch TX/RX Anzeige Funktion Tastensperre Batter-Status Lautstärke TX-Anzeige: Diese Symbol wird angezeigt, wenn gesendet wird. RX-Anzeige: Diese Symbol wird angezeigt, wenn auf dem ein- gestellten Kanal ein Signal empfangen wird.
All manuals and user guides at all-guides.com Betrieb Einsetzen des Akkus Das WT200 besitzt einen NiMH Akku. Zum Wechseln des Akkus gehen Sie wie folgt vor. Schalten Sie das Gerät aus. Entfernen Sie den Clip, indem Sie an der Oberseite die Lasche nach außen drücken und den Clip anschließend nach oben schieben.
All manuals and user guides at all-guides.com Betrieb Wenn das Gerät längere Zeit nicht genutzt wird, sollte der Akku entnommen werden, um Korrosion an den Kontakten zu vermeiden. Einsetzen der Batterien Alternativ kann das Gerät auch mit Batterien betrieben werden. Öffnen sie dazu das Batteriefach (siehe links) und legen dann, wie im Batteriefach markiert, 3 Batteriezellen AAA (Micro) ein.
All manuals and user guides at all-guides.com Betrieb Anschluss von externen Sprechgarnituren Als Option können externe Sprechgarnituren an der Headset / Lade- buchse auf der Oberseite des Gerätes angeschlossen werden. Um eine Beschädigung des Funkgerätes zu vermeiden, ver- wenden Sie bitte nur Originalzubehör. Schalten Sie das Gerät immer aus, bevor Sie eine externe Sprechgarnitur anschliessen und stellen Sie dann vorsich- tig die Lautstärke ein, um eine Beschädigung des Ohrhörers...
All manuals and user guides at all-guides.com Betrieb Sendebetrieb (PTT) Zum Senden halten Sie die PTT-Taste gedrückt und sprechen Sie mit normaler Lautstärke aus ca. 5-8 cm Entfernung in das Mikrofon. Solange die PTT-Taste gedrückt wird, erscheint die TX-Anzeige im Display. Um den Sendebetrieb zu beenden, lassen Sie die PTT-Taste los.
All manuals and user guides at all-guides.com Betrieb Sendebetrieb mit der Freisprecheinrichtung (VOX) Schalten Sie das Gerät mit der Ein-/Aus-Taste aus. Drücken Sie die Ein-/Aus-Taste, um das Gerät einzuschalten. Das Display zeigt jetzt das VOX-Symbol an . Positionieren Sie das Mikrofon der Sprechgarnitur ca. 5--8 cm vom Mund entfernt.
All manuals and user guides at all-guides.com Betrieb Um die Einstellungen zu übernehmen drücken Sie die PTT-Taste oder warten Sie 3 Sekunden, dann wird der Wert automatisch übernom- men. Tastatur-Ton Ist der Tastatur-Ton eingeschaltet, ertönt bei jedem Drücken einer Taste ein Ton(ausgenommen die PTT-Taste).
Das WT200 besitzt 8 PMR Kanäle. Pilotton (CTCSS) einstellen Das WT200 verfügt über insgesamt 38 Pilottöne, die im CTCSS-Stan- dard arbeiten. Mit diesen Pilotton-Rufnummern können Rufgruppen ge- bildet werden. Sie erreichen Ihren Gesprächspartner nur, wenn er auf dem gleichen Kanal und mit dem gleichen Pilotton (CTCSS) arbeitet.
All manuals and user guides at all-guides.com Betrieb führt werden. Um den Pilotton (CTCSS) einzustellen gehen Sie wie folgt vor: Drücken Sie 2x die Menü-Taste, bis im Display die Pilotton Nr. blinkt. Mit den Aufwärts-/ Abwärts-Tasten können Sie nun den gewünsch- ten Pilotton wählen (1 –...
All manuals and user guides at all-guides.com Betrieb Tastensperre (Lock) Um das Funkgerät vor einem unbeabsichtigten Verstellen zu schützen, können Sie die Tastensperre aktivieren. Zum Ein bzw, Ausschalten der Tastensperre gehen Sie wie folgt vor: Drücken Sie die Menü-Taste und halten diese ca. 3 Sekunden ge- drückt, bis im Display das Tastesperre-Symbol erscheint/er- licht.
All manuals and user guides at all-guides.com Technische Daten Frequenzbereich 446.00625 - 446.09375 MHz Kanäle 8 PMR Kanäle (12.5 KHz Kanalraster) Modulationsart FM (F3E) Frequenzabstimmung PLL Stromversorgung NiMH Akku Pack 3,6V 600mAh 3 x Alkaline Batterie 1,5V AAA Temperaturbereich -20/+55°C Antenne fest angebaut Anschlüsse...
Seite 19
All manuals and user guides at all-guides.com Contents Security instructions ..........…..…..20 Product information Features ................22 Name of each part ….………..........23 Name of displayed features ..........24 Starting operation Replace the battery ............25 Recharge battery .............. 26 Check battery condition ............26 External earset ..............26 Turn the radio on ..............27 Turn the radio off ..............27 General operation...
All manuals and user guides at all-guides.com Security instructions Please read this information carefully before you use the two way radio. General instructions Don’t use the unit while driving a car or riding a bike. Don’t place the unit on unstable location, if it falls down, people may be injured.
All manuals and user guides at all-guides.com Security instructions Contents security instruction of this device. Batteries Don’t leave empty batteries in the unit. Don’t try to recharge Alkaline batteries. Batteries can be extremely dangerous if accidentally swallowed. Therefore keep the unit out of reach of small children. Please do not throw the batteries into the regular garbage.
All manuals and user guides at all-guides.com Product information View of the appliance Antenna Socket for handfree kit Display PTT button Call button Ein/Aus-Taste Menu button Up-/ Down button Microphon Speaker charger pins (on the battery cover) - 23 -...
All manuals and user guides at all-guides.com Product information View of the appliance-Display Channel Scan icon Sub-channel, VOX icon (CTCSS) Dual-Watch icon TX/RX icon Buttonlock icon Battery condition Volume TX indicator: This icon appears, if transmitting is in process. RX indicator: This icon appears, when the radio receives a signal on the current channel.
All manuals and user guides at all-guides.com Getting started Replace the battery The WT200 has an rechargeable NiMH. If it is necessary to replace the battery, proceed as follows: Power off the unit. Pull the belt clip latch away from the unit and push up on the belt clip to remove it.
External earset Earsets can be connected to the radio on to Headset jack on the top of the radio. To avoid damage to the radio use only original dnt acces- sories. Turn off the radio before connecting external accessories. Adjust the volume to a low level to avoid injuries by hearing a loud signal.
All manuals and user guides at all-guides.com Getting started Turn the radio on To switch the radio on, press the On/Off button for 3 seconds until the dis- play shows ON and all icons and a tone is heard. After half a second the display changes to normal mode.
All manuals and user guides at all-guides.com General operation To enable VOX mode proceed as follows: Press Menu button three times until LCD displays VOX icon and VOX sensitivity digit display is fl ashing. Press Up-/Down button to select 1, 2, 3 for low, medium & high sensitivity.
All manuals and user guides at all-guides.com General operation Call-Ring tone You can use call tones to get the attention of other people with radios on the same channel and CTCSS tone. You can also use call tones as the signal of the start or end of a transmission.
Press the PTT button to confi rm or wait 3 seconds, the changes are be stored automatically. CTCSS code The WT200 has altogether 38 sub-channels which work in the CTCSS standard. A private sub-audible tone may be programmed and associated with every channel, to protect the radio from unwanted calls or interfer- ence from other operators on the same channel.
All manuals and user guides at all-guides.com General operation incoming messages will be received only from radios using the same CTCSS tone on that channel. To change the CTCSS code proceed as follows: Press the Menu button twice , CTCSS code display fl ashes. Press Up-/Down button to select your desired the CTCSS code (1~38, "...
All manuals and user guides at all-guides.com General operation If the button lock function is activated, only the PTT and Call button can be used. To disable the function proceed in the same way. Dual Watch The dual watch allows listening to a second channel Set main channel fi...
All manuals and user guides at all-guides.com Specifi cations Frequency Range 446.00625 - 446.09375 MHz Channels 8 (12.5 KHz spacing) Modulation Frequency Control P.L.L. Power Supply NiMH rechargeable battery 3,6V 600 mAh 3 x Alkaline battery 1,5V AAA Temperature Range -20/+55°C Antenna Integrated...
Sie von der nachfolgenden Seite als PDF-Datei herunterladen: http://www.dnt.de/konformitaet Hereby, dnt GmbH, declares that this YoungStar is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC (R&TTE). The declaration of conformity for this product can be downloaded from: http://www.dnt.de/conformity...
Seite 35
All manuals and user guides at all-guides.com Garantiebedingungen 1. Es gelten grundsätzlich die gesetzlichen Garantiebestimungen. Die Garantiezeit beginnt mit der Übergabe des Gerätes. Im Garantiefall ist das Gerät mit dem Kaufbeleg (Kassenzettel, Rechnung o.ä.), dem korrekt ausgefüllten Gerätepass und einer genauen Fehlerbeschreibung einzureichen.
All manuals and user guides at all-guides.com WT200 Garantiekarte Warranty card Drahtlose Nachrichtentechnik Entwicklungs- und Vertriebs GmbH Voltastraße 4 D-63128 Dietzenbach Tel. +49 (0)6074 3714-0 +49 (0)6074 3714-37 Internet http://www.dnt.de Email dnt@dnt.de Serien Nr. Serial no. Kaufdatum: Date of purchase: Stempel und Unterschrift des Händlers...
