Important Notes On The Product; Declaration Of Conformity; Technical Data - Motec MB1405-Quad Bedienungs- Und Montageanleitung

Make sure that the data indicated on the rating plate of the control box MB1405-Quad
correspond to this user manual. Please see the camera and monitor manuals for further
instructions.
As the initial vendor within Europe, we have conducted an evaluation of conformity for our
products in accordance with EU directives and legal provisions based on the requirements of
the relevant „harmonised standards". You will fi nd the CE marking on the product and also on
the accompanying product documentation. We will be happy to provide you with a separate EC
Declaration of Conformity upon request.
If modifi cations are made to the device, compliance with the requirements of conformity is
no longer ensured and the warranty becomes void. In case of use outside the EU, the user is
required to comply with relevant national requirements.
Voltage supply
Power input
Storage temperature
Operating temperature
Weight
Housing
Protection system
Shock resistance
Dimensions
Installation position
Mounting holes
Video inputs
Video outputs
Video input/output signal
Signal switching
Connections

1.1 Important notes on the product

1.2 Declaration of conformity

1.3 Technical data

12/24V DC
Max. 2.5 A
- 30° C ... +80° C
- 20° C ... +70° C
550 g
Metal
IP30
5 g
157 x 80 x 30 mm³
Any
4x ø4.5mm
4
1
FBAS / 1 Vss / 75 Ω
Manually via control lines
Alternatively via control unit
Video inputs: 4-pole min DIN
Monitor output: 9-pole SUB-D
Voltage supply: MINI-FIT JR.
GB
13
