b)
Plug connector "M"
Device socket "M" terminal allocation
Socket contact
Description
1
VID
2
VID_GND
3
-
4
GND
5
-
6
-
7
POC
8
-
9
-
c) Connectors C1 to C4 (camera 1 ... 4)
Device sockets C1 to C4 terminal allocation
Socket contact Description
1
VID
2
-
3
-
4
VCC
5
GND
3.3 Configuration of control cables
a) Configuration for vehicles without trailers
With vehicles without trailers (e.g. waste disposal vehicle) the control lines must be connected
as follows:
Configuration for vehicles without trailers
Control line
Function
Quad
Split-screen
POC
Display contact On/Off
SEL1
Control line 1
SEL2
Control line 2
SEL3
Control line 3
SEL4
Control line 4
9 pole SUB-D device socket
Function
Video signal
Video shield
-
Ground
-
-
Power 12V DC
-
-
4-pole mini-DIN device socket
Function
Video signal
-
-
Supply, positive terminal
Supply, negative terminal
Connection to
Contact
Switch plus
Reverse gear
Contact (e.g for dumping)
Contact +24V
Switch plus (e.g for front camera)
