3. First pull the back over the frame. Make sure the frame fits perfectly in the
corner of the tent and the top corners of the frame fit in the curve of the tent
4. Ensure that the rain tent lays straight on the frame and pull the front over the box
5. Feed the tie down straps through the sidebars and tighten slightly
6. Check again to ensure the rain tent is placed straight on the frame.
The easiest way to do this is by looking in the tent through the front and to
check that the handlebar is right in the middle. Moreover, the seam in the
middle of the top of the rain tent needs to run perpendicular to the handlebar
7. Is the tent in place? Then tighten all tie down straps (this can be quite tight),
so the tent is secure
8. Now you can close the zips by pulling them slightly towards you and then
down. Never pull the zip straight down!
IMPORTANT:
1. The tent will be quite tight after the first assembly. After a while the seams will be under tension and the
rain tent will become roomier.
2. In the beginning, it is advisable to pull the left and right zips down simultaneously, until the rain tent is
under tension. Once the tent is under tension, the zips will close and open more easily.
Step 3:
Opening the windows
Would you like to cycle with open windows? Fold the windows carefully and attach to the hook on the top of the
rain tent using the elastic band.
TIP:
A sunroof is also available for use in combination with the poles of the rain tent.
