Rain Tent Babboe Curve & Babboe Go - Manual for mounting
Congratulations on your new rain tent for your Babboe Curve or Babboe Go cargo bike! Below
you will find the instruction manual for the rain tent. To dismount the tent, follow the steps in
the reverse order.
Step 1:
Mounting the poles to the box
Mounting the poles to the carrier is simple, however, it should happen in the following order:
1. First, assemble the poles for the side of the handlebar (with the green sticker BACK) and then insert them into
the slots on the side of the handlebar up to wider section of the poles
2. Then, assemble the both parts of the central bar and then insert them into the inserted poles
3. Assemble the poles for the front side (with the red sticker FRONT) and insert them into the central part
4. Place the front poles into the slots on the front side up to wider section of the poles. This creates the
necessary tension on the poles, ensuring a secure structure.
Step 2:
Attaching the canvas
The order of assembly is essential for an optimum fit:
1. Unfold the tent canvas and unzip all zips
2. Place the canvas over the poles. The side with an opening for ventilation is placed at the side of the
handlebar.
