Levenhuk Atom Digital DNB200 Night Vision Binoculars
EN
Never, under any circumstances, look directly at the Sun, another bright source of light, or at a laser through this
device, as it may cause PERMANENT RETINAL DAMAGE and may lead to BLINDNESS.
Specifications
Magnification, x
Objective lens diameter, mm
Field of view, °
Close focus, m / ft
Observation distance, m / ft
Tripod adapter thread
Operating temperature range, °C / °F
IR-illumination
IR wavelength, nm
Recording time with illumination (IR), h
Recording time without illumination (IR), h
Daytime recording without IR
Recording at night (in the dark) with IR
Power supply
Storage
Screen
Language settings
Image format and resolution
Video format and resolution
Dimensions, mm / in
Weight, g / lb
The manufacturer reserves the right to make changes to the product range and specifications without prior notice.
Getting started
Install batteries
•
Open the battery compartment cover and insert 2 batteries according to the correct polarity marks. Close the cover.
Charging the device
•
Connect the power cable to the device and the DC adapter (not included) via a USB plug and connect it to the AC power supply.
Attention! The device operates from the AC power supply, as the voltage of the computer's USB port is insufficient for the proper
operation of the device.
Installing/removing the memory card
•
The device supports memory cards class 10 up to 128GB.
•
Insert the microSD card into the slot. Make sure the direction is right. Do not force the card in.
•
Format the microSD card before starting, as it will improve its compatibility with the device.
•
To remove the card from the slot, press the edge of the memory card in gently, and the card will pop out. Then, remove the card.
Note: If the memory card is not installed, a No Card icon will be displayed.
ON/OFF/SHOT button
Button functions: 1) turns the device on/off (a long press); 2) takes a picture in Photo mode; 3) starts and stops video recording in
Video mode; 4) enters the sub-menu.
Turn the focusing wheel to adjust the focus.
Notes:
•
If the device fails to activate, check for defective or improperly installed batteries. Always only use the recommended batteries.
•
If you wear glasses, keep them on while using the device.
1–5 (digital), 4 (optical)
24
10
5 / 16.4
250–300 (in complete darkness)
3–1000 (in weak light) /
820–984 (in complete darkness)
9.8–3280 (in weak light)
1/4"
−20...+60 (operating), −30...+70 (storage) /
–4...+140 (operating), −22...+158 (storage)
IR LEDs 6W
850
6
10
color image
black and white image
2pcs 18650 batteries, 3.7V 1200mA∙h
class 10, microSD up to 128GB
3", 640x360px
Chinese, English, French, German, Italian, Japanese, Korean,
Portuguese, Russian, Spanish
JPG; 10M/8M/5M/3M/VGA
AVI; 1920x1080px @30fps, 1280x720px @30fps
160x125x60 / 6.3x4.9x2.4
334 / 0.74
