Levenhuk Atom Digital DB10/DB20 LCD Binoculars
EN
Never, under any circumstances, look directly at the Sun, another bright source of light, or at a laser through this
device, as it may cause PERMANENT RETINAL DAMAGE and may lead to BLINDNESS.
Specifications
Product ID
Model
Magnification, x
Objective lens diameter, mm
Field of view, °
Close focus, m / ft
Observation distance, m / ft
Operating temperature range, °C / °F
Power supply
Storage
Screen
Image format and resolution
Video format and resolution
Language settings
Tripod adapter thread
Dimensions, mm / in
Weight, g / lb
The manufacturer reserves the right to make changes to the product range and specifications without prior notice.

Getting started

Install batteries

•
Open the battery compartment cover and insert the battery according to the correct polarity marks. Close the cover.
Charging the device
•
Connect the power cable to the device and the DC adapter (not included) via a USB plug and connect it to the AC power supply.
Attention! The device operates from the AC power supply, as the voltage of the computer's USB port is insufficient for the proper
operation of the device.
Installing/removing the memory card
•
The device supports memory cards class 10 up to 32GB.
•
Insert the microSD card into the slot. Make sure the direction is right. Do not force the card in.
•
Format the microSD card before starting, as it will improve its compatibility with the device.
•
To remove the card from the slot, press the edge of the memory card in gently, and the card will pop out. Then, remove the card.
Power on/off
Press and hold the POWER button until the LCD screen is on in order to turn the device on.
MENU button
To change the settings, press the MENU button and highlight the desired menu item by scrolling up or down using the Right and Left
buttons.
Select the highlighted item by pressing the Camera/OK button.
In the menu, you can select photo or video resolution, change the language, set the date, set auto power off, format the memory
card, view and delete the current file or all files from the memory card, etc.
Note! To get to the submenu of the playback mode, you need to select the playback mode first (MODE button).
MODE button
This button switches between 3 in-built modes: 1) photo mode; 2) video mode; and 3) playback mode.
81703
Levenhuk Atom Digital DB10 LCD
digital: 1–8
optical: 10
25
−20...+60 (operating), −30...+70 (storage) /
−4...+140 (operating), −22...+158 (storage)
rechargeable lithium polymer battery, 3.7V 1000mA∙h
2", 320x240px
JPG; 40M/30M/25M/20M/10M/8M/5M/3M
AVI; 2.5K/1080p FHD/1080P/720P
Chinese, English, French, German, Italian, Japanese, Korean, Portuguese, Russian,
160x125x60 / 6.2x4.9x2.3
287 / 0.6
4
Levenhuk Atom Digital DB20 LCD
8
10 / 32.8
10–1000 / 32.8–3280
class 10, microSD up to 32GB
Spanish
1/4"
144x97x63 / 5.6x3.8x2.4
81704
digital: 1–8
optical: 12
32
2.4", 320x240px
460 / 1.0
