loose control of the tool, and result in
personal injury.
SYMBOLS
Read the instructions.
Safety class II.
Wear ear protection.
Wear safety glasses.
Wear a dust filter mask.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.

TECHNICAL DATA

Rated voltage
Output
Chuck size
Capacity in concrete
Capacity in steel
Capacity in wood
Speed
Stroke rate
Cord length
Weight
Sound pressure level, LpA 87.6 dB(A), K=5 dB(A))
Sound power level, LwA
Vibration drilling in metal ah, D
Vibration percussion drilling in concrete ah, ID
230 V ~ 50 Hz
500 W
13 mm
10 mm
8 mm
20 mm
900 rpm
0-46400/min
1.8 m
1.6 kg
98 dB(A), K=5 dB(A)
4.935 m/s², K=1.5 m/s
15.558 m/s², K=1.5 m/s
Always wear ear protection!
The declared values for vibration and noise,
which have been measured by a standardised
test method, can be used to compare different
tools with each other and for a preliminary
assessment of exposure. The measurement
values have been determined in accordance
with EN 62841-2-1:2018.
WARNING!
The actual vibration and noise level when using
tools may differ from the specified maximum
value, depending on how the tool is used
and the material. It is therefore necessary to
determine which safety precautions are required
to protect the user, based on an estimate of
exposure in actual operating conditions (taking
into account all stages of the work cycle, e.g. the
time when the tool is switched off and when it is
idling, in addition to the start-up time).
DESCRIPTION
Hammer drill (500W) for wood, concrete
and metal with rubber coated grips. It also
has adjustable speed control and forward/
backward rotation.
PARTS
1. Selector drilling/percussion drilling
2. Power switch lock
3. Cord with holder for chuck key
4. Power switch with speed control
5. Rotation selector
6. Support handle
7. Depth stop
8. Chuck
9. Chuck sleeve
10. Scale for depth stop
11. Chuck key
FIG. 1
