Technical Data - MTR+ Rehalito Bedienungsanleitung

Channels:
Waveform:
Intensity:
Classification:
Frequency:
Pulse Width:
Time Settings:
Max. Voltage:
Battery;
Dimensions of the device: H 11,7 cm / W 6,6 cm / D 3,3 cm
Weight of the unit: 150 g (incl. battery)
Firmware version: 3.1 or later
Max. environmental conditions for transportation: -25 to +70 degree centigrade, 0-93%
atmospheric humidity. Recommended environmental conditions for storage: -25 to +40 degree
centigrade, 0-93% atmospheric humidity. The device shall not to be stored in direct sunlight.
Allow up to one hour for the device to return to normal operating temperature if stored in
conditions below +5°C or above +40°C.
Environmental conditions for use: +5 to +40 degree centigrade, 0-93% atmospheric humidity,
air pressure 700-1060 hPa. During use the surface temperature of the device can be 41°C or
higher, but never exceeds 48°C.
The Rehalito is protected against debris larger than 12.5 mm in diameter from entering the
cabinet, is not water resistant and rated IP20.
The patient is the intended operator for this unit. This device is quality controlled and fulfills all
legal requirements for medical products. Therefore this device carries the CE-sign „CE 0123".
The serial number is on the rear of the unit.
Manufacturer:
Kamenzer Damm 78, 12249 Berlin, Germany
www.mtrplus.com
Rehalito Bedienungsanleitung / Operators Manual

Technical Data

Two isolated independent channels
Asymmetrical, rectangular. bi-phasic with zero DC current
0 - 80 mA into 500 ohm load
80 mA maximum into 1000 Ohm load
70 mA maximum into 1500 Ohm load
(Indication only, actual intensity varies depending on
condition of skin electrodes)
Internally powered, constant current, continuous operation,
Type BF applied part, class IIa, IP20
1 - 150 Hz (Burst 35 - 150 Hz)
50 - 450 µS (Burst 50 - 200 µS)
Variable 1 minute to 9 hours 59 minutes (custom program)
180 V without load (70V with 1000 ohm load)
9 Volt 6LR61 / 6AM6 recommended
MTR+ Vertriebs GmbH,
