SYSTEM
INFO, RESET, SERVICE, TEST....
HEATING CABLE & PIPE
CABLE TYPE, PIPE DAIMETER,...
GENERAL SETTINGS
HEATING CABLE & PIPE
COUNTRY, LANGUAGES, UNITS,...
WATER TEMP. & PROGRAM
APPARTMENT, MAINTAIN, ECONOMY,....
HEATING CABLE & PIPE
SELECT CABLE TYPE
SELECT PIPE DIAMETER
INFO
SELECT INSULATION THICKNESS
TEST PROGRAM
SELECT AMBIENT TEMPERATURE
RESET
SELECT BOILER SENSOR
SERVICE
SELECT BOILER CUT-OFF TEMPS.
STATUS
Selection of
Every parameter line shows the actual value /attribute for
parameters
each parameter.
Heating cable Select the type of cable used in your installation (DHB 200).
Pipe
Set the pipe diameter. You can change the value from
diameter
DN 15 mm up to DN 125.
Insulation
Set the insulation thickness. You can change the value from
thickness
9 to 130 mm, with the pipe diameter as the limiting value.
Water
Activate/deactivate a connected boiler sensor by clicking
heater
on ON/OFF. The external temperature sensor measures the
sensor
water heater temp. The trace water heater setting is included
to ensure that the heating cable temperature does not exceed
the water heater temperature. The Therm-Control memorizes
the highest measured temp. over the last 24 hours.
If the water heater temp. is too low, the maximum temp. is
lowered to the water heater temp. minus the trace temp.
In this case the green trace water heater LED will be on.
Boiler low
You can determine the low temperature limit. If the water
temp. limit
heater temp. reaches this value, the unit will switch off the
heating system in order to fulfil hygienic requirements and
avoid energy waste.
Boiler high
You can determine the high temperature limit. If this value is
temp. limit
reached the unit will switch off the heating system to avoid
scalding.
Pipe sensor
activate/deactivate a connected pipe sensor by pressing ON/
OFF. The pipe sensor monitors the pipe temperature and
needs to be installed close to the furthest point in the pipe
distribution network.
Pipe sensor
You can determine the low temperature limit. When the value
is reached a warning will appear on the screen but will not
low temp.
interrupt the unit's functioning. The info status screen will
limit
show the actual pipe temperature.
You can determine the high temperature limit. A warning will
Pipe sensor
appear on the screen when the value is reached but will not
high temp.
interrupt the unit's functioning.
limit
14 : 17
DHB 200
SYSTEM
DN 25
40 MM
20 °C
ON
35/85 °C
SELECT WATER TEMPRATURE
SELECT PROGRAM
PROGRAM TIMER
14 : 17
