• Use a pen to mark the positions of the two bore
holes with a distance of 13.6 cm on the wall (see
figure 3).
• Use an appropriate drill to make the holes as il-
lustrated.
• Use the supplied screws and plugs to fasten the
Floor Heating Controller (see fig. 3).
5.2

DIN rail mount

For mounting the Floor Heating Controller to a DIN rail,
please proceed as follows:
• Place the Floor Heating Controller onto the DIN
rail (see fig. 4).
• Latch the Floor Heating Controller by pressing
the spring latches (E) upwards (see fig. 4).
• Make sure that the spring latches are completely
latched and that the device is seated solidly on
the rail.
6

Start-up

6.1

Installation instructions

Please read this entire section before starting to
install the device.
Please note! Only to be installed by persons with
the relevant electro-technical knowledge and
experience!*
