Check the Brakes
❶
centering and brake lever travel. If the brake pads are no
longer square to the rim, repeat brake pad adjustments.
Figure 3.10
❷
spinning the wheel and listening for the brake pad rubbing
the rim on either side. Re-adjust as needed.
❸ Check that the brake cable tension allows the brake lever
about 1/3 of the travel before the brake pads contact the
rim. If the cable has stretched or slipped, re-adjust the brake
cable tension by loosening cable anchor bolt and pulling
more cable through the anchor or use brake adjustment
Brake is correctly adjusted when:
• The brake pads do not drag on the rim when the brake is
open. Figure 3.11
• Both brake pads move away from the rim equally when the
brake is released.
• When the brake is applied, the brake pads contact the rim
before the brake lever reaches about 1/3 of the way to the
handlebar.
1/3 distance to
handlebar
Equal space
between brake
pad and the rim
on both sides
Brake pads
Wheel rim
49
1
Figure 3.10
Figure 3.11
25
