HOMCOM 371-042 Benutzerhandbuch Seite 48

Important! Before riding the scooter it is important to check the
brakes. If you squeeze the brake lever and one brake arm moves
more than the other, (or not at all), the brake is not centered.
may be necessary to center the brake pads, correctly set the
brake pressure, and set the gap between the brake pad and rim.
❶ Check that all brake pads are aligned correctly. If not, use a
5 mm allen wrench and loosen the bolt enough so you can
correctly. Figure 3.6
Incorrect Alignment
Correct Alignment
Center the Brake Pads
Rotate the wheel and look straight down at the gap between
the rim,
are uneven it indicates the wheel, the brake pads, or both are
not centered.
❶ If you see the gap between the fork and wheel is uneven
Figure 3.7
Wheel should
be centered
Axle nuts
Figure 3.6
47
Even space
between
wheel and fork
(both sides)
Figure 3.7
