AC/DC Voltage "V / mV" Measurement
1. Turn the rotary switch the measurement function " " or "
and select either the AC or the DC voltage function with the
"FUNC." button.
2. When dealing with an unknown voltage range, always start
with the higher measurement range " " then switch to the
lower range "
3. Insert the red probe in the "
probe in the "COM" socket.
4. Connect the probes' tips (red probe is the positive pole, black
probe is the negative pole) in parallel to the measuring circuit,
measure the voltage.
5. The measurement result is displayed on the screen.
", if applicable.
" socket and insert the black
14
"
