CLASSIFICATION
SUBJECT
11. L&R CHANNEL SEPARATION: (1KHz, 0dB, INPUT, GAIN /AUX AT 12 O'CLOCK, MASTER AT 12
O'CLOCK, WITH A-w/20kHz LPF )
LINE/CD/AUX： 80dB
PHONO：
12. EQUALIZER RESPONSE: (GAIN/MIC/AUX AT 12 O'CLOCK , MASTER AT 12 O'CLOCK )
LINE：
(1) Low Band：(Low Band Reference Frequency is 70Hz)
Maximum level：
Minimum level：
(2) Middle Band：(Middle Band Reference Frequency is 1KHz)
Maximum level：
Minimum level：
(3) High Band：(Hi Band Reference Frequency is 13KHz)
Maximum level：
Minimum level：
MIC：
(1) Low Band：(Low Band Reference Frequency is 100Hz)
Maximum level：
Minimum level：
(2) High Band：(Hi Band Reference Frequency is 10KHz)
Maximum level：
Minimum level：
PHONES：
Hi：
Low：
44
GENERAL SPECIFICATION
Nominal Limited
75dB
80dB 75dB
+9
-26
+9
-26
+9
-26
+12
-12
+12
-12
-29
-29
HANPIN ELECTRON(SHENZHEN) CO., LTD.
FENGHUANG INDUSTRIALDISTRICT,FU YONG TOWN, SHEN ZHENCITY, GUANG DONG ,CHINA
@BETWEEN L AND R CHANNEL AT 0dBV INPUT
@BETWEEN L AND R CHANNEL AT -35dBV INPUT
Nominal Limited
± 1.5dB ± 2dB
± 1.5dB ± 2dB
± 1.5dB ± 2dB
± 1.5dB ± 2dB
± 1.5dB ± 2dB
± 1.5dB ± 2dB
Nominal Limited
± 1dB ± 1.5dB
± 1dB ± 1.5dB
± 1dB ± 1.5dB
± 1dB ± 1.5dB
Nominal Limited
± 1dB ± 1.5dB
± 1dB ± 1.5dB
1-3
PAGE
DATE
AT 100Hz
AT 10KHz
APPROVAL CHECK
(V0.13, 121416)
DESIGN
