CLASSIFICATION
SUBJECT
6. MAXIMUM INPUT: (1KHz, INPUT, GAIN AT MAX, MASTER AT 12 O'CLOCK, WITH A-w/20kHz LPF,
OUTPUT LEVEL LESS THAN 1%)
LINE/CD/AUX：
PHONO：
MIC1/2：
7. FREQUENCY RESPONSE: (1KHz, 0dB, INPUT, GAIN/MIC/AUX AT 12 O'CLOCK, MASTER AT 12
O'CLOCK)
LINE/CD/AUX： 20 - 20K Hz
PHONO： 20 - 20K Hz
MIC1/2： 20 - 20K Hz
（1KHz, 0dB, INPUT , GAIN/MIC/AUX AT 12 O'CLOCK , CUE AT 12 O'CLOCK )
CD 20 - 20K Hz
8. S/N RATIO: (1KHz,0dB,INPUT, GAIN/MIC/AUX AT 12 O'CLOCK, MASTER AT12 O'CLOCK, WITH
A-w/20kHz LPF)
LINE/CD/AUX：
PHONO
MIC1/2：
9. THD + N: (1KHz, 0dB,INPUT, GAIN/MIC/AUX AT 12 O'CLOCK, MASTER/BOOTH AT 12 O'CLOCK,
WITH A-w/20kHz LPF)
LINE/CD/AUX：
PHONO：
MIC1/2：
（1KHz, 0dB, INPUT , GAIN/MIC/AUX AT 12 O'CLOCK , CUE AT 12 O'CLOCK,WITH A-w/20kHz LPF )
CD：
10. CROSSTALK: (1KHz, 0dB, INPUT, GAIN AT 12 O'CLOCK, MASTER AT 12 O'CLOCK, WITH A-w/20kHz
LPF)
Nominal
LINE/CD： 90dB
PHONO： 90dB
HANPIN ELECTRON(SHENZHEN) CO., LTD.
FENGHUANG INDUSTRIALDISTRICT,FU YONG TOWN, SHEN ZHENCITY, GUANG DONG ,CHINA
GENERAL SPECIFICATION
Nominal
MORE THAN +12 dBV
MORE THAN -23 dBV
MORE THAN -30 dBV
Nominal
+1/-1.5 dB
+1/-2 dB
+1-2 dB
+1/-1.5dB
Nominal
83dB
83dB
70dB
Nominal
0.01 %
0.02 %
0.03 %
0.02%
Limited
80dB @EACH CHANNEL INPUT AT 0dBV INPUT
80dB @EACH CHANNEL INPUT AT -35dBV INPUT
PAGE
DATE
Limited
MORE THAN +11 dBV
MORE THAN -25 dBV
MORE THAN -32 dBV
Limited
+2/-3 dB AT 0 dBV INPUT
+2/-3 dB AT -50 dB INPUT(RIAA)
+2/-3 dB AT -42 dBV INPUT
+2/-3dB AT 0dBV INPUT
Limited
77dB AT 0dBV INPUT
77dB AT -35dBV INPUT
65dB AT -42dBV INPUT
Limited
0.02 % AT 0dBV INPUT
0.05 % AT -35dBV INPUT
0.06 % AT -42dBV INPUT
0.05 % AT 0dBV INPUT
APPROVAL CHECK
1-2
DESIGN
(V0.13, 121416)
