AUX channel functions
The AUX channel (= 3-position switch) is normally switched off, but it can be activated for
special purposes ("AUX-Channel Function" parameter in LIMITS menu).
The possible options for the "AUX-channel func" parameter are:
Option Description
NOT USED
AUX channel not in use (
receiver)
This is the default setting
Starting the turbine:
1. Rpm-slider back (if green LED flashes)
2. Rpm-slider to idle (min. 1 second)
3. Rpm-slider to max rpm -> start
4. Rpm-slider back to idle
Shutting down the turbine :
The post-run cooling process for the turbine is always active, and cannot
be disabled.
ON, TrbCtrl ON
AUX channel in use (
The turbine is controlled (OFF/RUN/AUTO-OFF) via the AUX switch (3-
position switch).
ON, TrbCtrl OFF AUX channel in use (
The AUX channel is active, but is only used for the functions of controlling
the Smoker valve. The turbine is controlled using the throttle channel
only.
Starting the turbine:
1. Rpm-slider back (if green LED flashes)
2. Rpm-slider to idle (min. 1 second)
3. Rpm-slider to max rpm -> start
4. Rpm-slider back to idle
Shutting down the turbine :
The post-run cooling process for the turbine is always active, and cannot
be disabled.
AUX lead does not have to be connected to
OFF
Rpm-slider back
AUX lead must be connected to receiver)
AUX lead must be connected to receiver)
OFF
Rpm-slider back
67
