Seite 1
MONTAGE- UND BEDIENUNGSANLEITUNG ASSEMBLY INSTRUCTIONS INSTRUCTIONS DE MONTAGE R 3000 Fachbodenregal Premium R 3000 Modular Shelving Premium R 3000 Rayonnages à Premium MADE IN MADE IN GERMANY GERMANY...
2.3 Bedien- und Nutzungs hinweise / Maintenance and user guidelines / Conseils d‘utilisation et de manipulation max. 200 kg Fachlast max. 200 kg Shelf load max. 200 kg Charge par étagère max. 200 kg Feldlast max. 1500 kg max. 200 kg Bay load max.
7.0 Rückwand außen (optional) / Outer back panel (optional) / Panneau dorsal extérieur (optionnelle) Achtung! Bei Regalfeldern mit Kreuz verband Halteleiste oben oberhalb und unten unterhalb der Kreuzverbandlaschen einhängen. Warning! For shelf sections that have cross brace insert holding rails into place above and below the cross brace.
8.0 Teleskopschiene / Telescopic rails / Montage des glissières de tiroirs Achtung! Warning! Beim Einbau mehrerer Schubladen oder Aus- When fitting several drawers or extendable Attention ! zugsböden ohne Auszugssperre ist eine Ver- shelves, it is required to have a connection Pour le montage de plusieurs tiroirs ou tablettes bindung von Regalen untereinander (z.B.
11.0 Flügeltür / Double door / Montage de portes à double battant Regalrahmen Upright Echelle DIN 603 M8x45-8.8-VZ DIN EN1661 M8-8-VZ Scharnierleiste Scharnierleiste Hinge trim Hinge trim Profilé d‘accrochage Profilé d‘accrochage inférieur inférieur Scharnierleiste Hinge trim Tringle charnière supérieure DIN EN1661 M8-8-VZ DIN 603 M8x45-8.8-VZ Scharnierleiste...
12.0 Flügeltürjustierung / Adjustment of double door / Règlage des portes Flügeltür Double door Portes battantes Flügeltür Double door Portes battantes 13.0 Freistehende Trennwand / Free standing 14.0 Etikettenhalter / Label holder / porte- divider / Paroi séparatrice libre étiquettes Freistehende Trennwand Free standing divider Paroi séparatrice libre...
Seite 12
15.0 Bodenbefestigung von Regalrahmen/ Securing rack uprights to the ground / Fixation au sol HUS3-H6 x 60 HUS3-H6 x 60 6 mm Unterlegplatte Underlay plate Plaquette de nivellement Unterlegplatte Underlay plate Plaquette de nivellement Einfachzeile / Single line / Ligne de rayonnage simple Doppelzeile (Rahmendistanz bis 6mm) / Double line (frame distance up to 6 mm) / Ligne de rayonnage double (distance entre échelles jusqu’à...
