 Motion Sensor
Model: DWM1301
Operating Temperature: 32° F to 113° F ( 0° C to 45° C)
Frequency: 433.92MHz +/-150KHz
Modulation: ASK
Transmit Power: >= -16dBm(Manufacture's test condition)
Detection Type: Magnetic separation trigger function
Magnet Sensor Gap Activated: ~25mm (Reference)
Power source: CR123A 3V
Standby Current: <3uA
Operating Current: <=15mA
Battery Low Level Indicator: 2.1 V-2.35V
Low Battery Alarm Mode: Low battery alarms only when
Unpick Detection: Tamper switch wireless alarm
Model: PIR1301
Operating Temperature: 14° F to 122° F ( -10° C to 50° C)
Frequency: 433.92 MHz +/- 150KHz
Transmit Power: >= -16dBm(Manufacture's test condition)
Modulation: ASK
Oplink Communications, Inc.
another sensor alarm is triggered
