 Door/Window Sensor
Wireless interface: EEE 802.11 b/g/n, WPA2-PSK
Power Adapter:
5V,1A
Model: DWM1300
Operating Temperature : 32° F to 113° F (0° C to 45° C)
Frequency: 433.80MHz – 434.1-MHz
Modulation: ASK
Transmit Power: > -51dBm(Manufacture's test condition)
Detection Type: Magnetic separation trigger function
Magnet Sensor Gap Activated: ~11mm (Reference)
Power source: 1.5V*2pcs"AAA" Lithium and Iron
Disulfide battery
Standby Current: <10uA (@3.3VDC)
Operating Current: <18mA (@3.3VDC)
Battery Low Level Indicator: 2.2V-2.4V
Low Battery Alarm Mode: Low battery alarms only when
Unpick Detection: Tamper switch wireless alarm
Oplink Communications, Inc.
another sensor alarm is triggered
