3. Mount the license plate on the license plate bracket.
4. Choose a routing path for the
reverse light circuit. If in doubt, seek professional installation assistance.
5. Some vehicles may have a hole available to pass the wire through, such as where the
license plate light is mounted, or you can drill a hole close to where the power cable
is attached to the camera. Once you have chosen where the cable will enter the
the next two steps.
6. Before you drill a hole you MUST CHECK and see WHAT IS BEHIND WHERE YOU ARE
DRILLING. If there are any vehicle components, such as electrical parts or fuel
system components behind where you are drilling, you must take whatever
precaution is necessary not to damage them. Remove the license plate and camera
before drilling.
7. After you have drilled the hole, insert the supplied grommet, then pass the camera
cables through the grommet into the vehicle. You must use the grommet to prevent
the metal edge of the hole from cutting the camera cable.
8.
the accessory position, engage the parking brake and put the car in reverse. Look at
9. Once you have located the reverse light circuit you will have to route the camera
cable to that location. You must securely fasten the power cable to prevent it from
being caught on any vehicle component such as the trunk hinge. Never route the
cable on the outside of the vehicle!
10. The reverse light sockets on most
vehicles have two wires connected to
them. Usually the negative wire is
black and the positive wire is a colored
wire. If you are uncertain about the
wiring, you
multimeter available
parts stores to determine which is the
positive wire.
safe use of the multimeter.
can use a 12V/24V
at most
Follow
If you are able to use an existing opening, skip
cle specific wiring diagrams.
auto
the
5
located, they are the white
