Changing the Direction of Opening the Door
The door of the refrigerator can be opened both from the left or right as required. The
following are the steps required to position the door to open to the right.
1. Remove the lower bracket (1) on the right, the door and the screw hole cover (4).
2. Remove the lower bracket pivot (3) and the spring washer(2), and then place and fix
them in the hole on the left of the lower bracket.
3. Remove the cover (5) on the upper brackets on both left and right sides; remove the
bracket pivot on the right side and the spring washer and then fix them in the bracket
hole.
4. Fix the door between the upper and lower brackets on the left and fasten the lower
bracket by tightening the screws.
5. Fix the screw hole cover in the lower bracket hole on the right, and then fix the upper
bracket covers to the upper brackets on the left and right.
6. After installation open and close the door to ensure the door operates smoothly.
7. Move the components (7) and (8) with the special tool provided.
8. Remove the screw (9) from the refrigerator, open the door fully and replace screw (9) in the
corresponding opposite position.
9. Remove and replace component (10), at the corresponding position on the left, with the
special tool provided.
10. Fix component (7) in the corresponding opposite position.
RERFIG ERATOR COMPARTMENT
12
FREEZER COMPARTMENT
Instructions for Use
