Fitting furniture board to appliance
door
Parts List:
1. Fridge Door x 1
2. Wooden Door x 1
3. Right Frame x 1
4. Left Frame x 1
5. Top Frame x 1
6. Bottom Frame x 1
7. Self-Tapping Screws (ST3.9x16) x 10
Installation Steps:
Fit the bottom frame (5) on the bottom edge of fridge door (1) with 3 screws (7).
Screws should not be too tight so that the bottom frame could be adjusted if necessary.
Fit the left (4) and right (3) frames on to the sides of fridge door (1) with 4 screws (7). Screws should
not be too tight so that the frames could be adjusted if necessary.
Put the wooden door (2) into the gap of the frames along the direction of the arrow, adjust the frames
(3\4\5) to ensure the frames could hold the wooden door (2) properly.
Fit the top frame (6) on the top edge of the fridge door (1) with 3 screws (7).
Adjust the four frames (3/4/5/6) to fit properly and tighten the screws (7).
Instructions for Use 7
