5 | Installation
3. Feed the bus cable with the protective
conductor through the hole. Secure
the cable connection in the hole
[ Photo 22].
4. Guide the bus cable in the unit to the
fan motor. Guide the unit in such a
way that it is not affected by heat
sources. Observe the cable routing for
the respective unit size [
Unit Handling the bus cable...
size
6-1/1 Pass the steam generator and go
/ 6-2/ directly to the fan motor
1
10-1/1 Between the steam generator and
/ 10-2 lower fan motor over to the upper
/1 fan motor
20-1/1 Left next to the lower and middle
/ 20-2 fan motor over to the top ventila-
/1 tion motor
1. Disconnect the dummy plug from the
fan motor and connect the bus cable
from the condensation hood
[ Photo 24].
2. Check the cable routing to the ventila-
tion motor. If there is still any cable
length remaining, pull the bus cable
straight and secure the rest of the
cable in the electrical compartment
with a cable tie. Screw the cable con-
nection.
3. Fix the cable to the rear side of the unit
with the self-adhesive cable holders
supplied.
4. Connect the protective conductor
from the bus cable to the ground con-
nection on the housing of the steam
generator [ Photo
5. Mount the left side panel of the unit
(Combi-Duo: upper unit).
80.51.570_iCombi Pro-iCombi Classic_UV P_IM_V01_EU-west
Photo 23]:
25].
For Combi-Duo: First connect the second
bus cable in the lower unit before you con-
nect the condensation hood to the unit
(see } Combi-Duo: Additional connec-
tions).
5.2.3 Combi-Duo: Additional
connections
Only for Combi-Duo superstructures.
Using the add-on kit for Combi-Duo, the
UltraVent condensation hood can be con-
verted for operation for Combi-Duo.
Connecting the second bus cable in the
condensation hood
Connect the additional, longer bus cable
from the Combi-Duo retrofit kit to the
control board of the condensation hood
and to the lower unit.
a
The first bus cable and the protective
conductor are connected to the top
unit (see } Connecting the bus
1. Loosen the 4 screws securing the heat
shield and remove the heat shield
[ Photo 26].
2. Remove the left and right impact filter
[ Photo 9] and the cover to the elec-
trical compartment [
3. Loosen the 4 screws holding the elec-
tronics module and take out the elec-
tronics module [
4. Plug the bus cable from the add-on kit
to the free bus interface on the control
board [ Photo
5. On the rear of the condensation hood,
loosen the 4 screws securing the cover
to the electrical compartment and re-
move the cover [
the gasket of the cover for when you
reassemble the hood.
en
cable).
Photo 10].
Photo 27].
28].
Photo 29]. Keep
