DMX operation
Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 6 control channels.
However, it can also be switched to a mode with 2 or 4 channels if different functions are required. To be
able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller's documentation.
1
Press the MENU button so many times until DMX is indicated in the display. Confirm with the ENTER
button.
2
The display indicates 2 CH (2 DMX channels), 4 CH (4 DMX channels) or 6 CH (6 DMX channels). Use
the buttons UP and DOWN to select the desired number of DMX channels. Confirm with the ENTER
button.
3
Now the display indicates the menu item for the DMX start address ADDR:. Use the buttons UP and
DOWN to set the address. Confirm with the ENTER button.
4
The display will not blink when DMX signals are being received. If no control signals are available, the
display will blink.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
Functions in DMX mode
2-channel mode
Channel
1
2
4-channel mode
Channel
1
2
3
Master dimmer
4
Strobe effect
6-channel mode
Channel
1
Master dimmer
2
Strobe effect
3
4
5
Auto- and Sound
program
Value
000 – 255
Warm white 0-100%
000 – 255
Cold white 0-100%
Value
000 – 255
Warm white 0-100%
000 – 255
Cold white 0-100%
000 – 255
Total brightness 0-100 %
000 – 009
No function
010 – 255
Strobe, slow > fast 100%
Value
000 – 255
Total brightness 0-100 %
000 – 009
No function
010 – 255
Strobe, slow > fast 0-100%
000 – 255
Warm white 0-100%
000 – 255
Cold white 0-100%
000 – 009
No function
010 – 049
Auto program 1: slow > fast
050 – 089
Auto program 2: slow > fast
090 – 129
Auto program 3: slow > fast
31/36
Function
Function
Function
00138004, Version 1.0
