Environmental safety
This signal lamp contains a lead-gel accu. Dispose
of lead batteries as special waste.
Emergency light function
In case of power failure the signal lamp switches on
automatically. In this case proceed as follows:
1. Turn on signal lamp
2. Set required type of light (halogen/LED)
3. Connect charger with charging mount
4. Connect charger with 230V power socket – the
lamp turns off
Simulation emergency light function
Remove the charger from the 230V power socket – the
signal lamp turns on automatically.
2 brightness levels
Light duration
Lighting range
Illuminant
Battery
Charger
Charging time
Dimension (L x B x H)
Weight
Features
At the end of its useful life, this product must not be disposed of together with normal household
waste, but has to be dropped off at a collection centre for the recycling of electrical and electronic
devices. This is indicated by the symbol on the product, on the instruction manual or on the pa-
ckaging.
The materials of which this product is made are recyclable pursuant to their labelling. With the reuse,
the recycling of the mater als or other forms of scrap usage you are making an important contributi-
on to the protection of the environment.
Please ask your local administration office for the appropriate disposal centre.
All manuals and user guides at all-guides.com

Technical specifications

1: max. luminosity with halogen light
2: approx. 15% with LED light
Halogen: approx. 2,5 hours
LED: approx. 30 hours
Halogen: approx. 600 m
LED: approx. 50 m
Halogen: 5,5 V 1 A
LED: 8 LEDs
6 V 4 Ah, maintenance-free with total discharge protection
9 V 500 mAh
approx. 7 – 8 hours
125 x 75 x 300 mm
1,65 kg
Emergency light, 12V adapter, battery indicator, electronic charging circuit, light
pane yellow (removable), splash proof
Environmental Protection Notice
Electronic total discharge protection
Avoids damaging total discharge of the accu. This pro-
longs the lifetime of the accu and protects the envi-
ronment.
Battery
The lead-gel accu of the signal lamp can be charged
approx. 300 – 400 times. Replace it by batteries of the
same type only.
Exchange of 5.5V halogen bulb
Open lamp cover counter clockwise and remove it.
Loosen safety screw at the halogen bulb and exchange
bulb. Perform assembly in reverse order.
