Raddy RF760 Bedienungsanleitung Seite 23

(SQ.ON.01~SQ.ON.09). If the SQ OFF is not needed, please
short press [SET] for the second time. When the SQ
(SQ.ON.01~SQ.ON.09) is flashing, short press MODE to select
(SQ.OFF.00) to turn off the SQ OFF.
14.5.3 Short press [SET) for the third time to enter the ATT
state to display (NORMAL) mode; the (DX) or (LOCAL) display
will flash and then short press [SET] to select (DX) or (LOCAL)
setting and short press [SET]. Then, (ATT) (DX) or (LOCAL)
stops flashing. (DX) or (LOCAL) will exit if there is no operation
within five seconds and the work will be switched to be the
current default setting.
14.5.4 Short press [SET] for the fourth time and "■AM"
display will flash. Short press [MODE] to start narrowband
frequency modulation "NFM". Then, "NFM" display will flash.
Then, short press [MODE] and "■AM" display will flash. Then,
long press [MODE] for two seconds to exit "NFM".
14.6 VHF(UHF) state:
14.6.1 Short press [SET] for the first time. When (BW) flashes,
short press [MODE] to set the bandwidth to be 1.70KHz,
4.50KHz, 3.75KHz, 2.50KHz.
Vhf and UHF bands can be used for commercial an amateur
radio channels. The commercial radios will almost always be
FM, with a bandwidth available of 7.5 kHz for narrowband and
15 kHz for wideband.
The amateur radio channels can be wide or narrowband FM,
USB, or AM. For wide or narrow band FM, then 15 kHz and 7.5
kHz is appropriate. In USB, 2.5 kHz will work. In am, 8.0 kHz is
appropriate.
14.6.2 Short press [SET] for the second time, the SQ setting
(SQ.OFF/ON.00) flashes. Then, short press [MODE] to select
SQ of (SQ.ON.01~SQ.ON.09).
21
RF760 Full-Band Radio
