4. Connect the brass connector on the tubing to
the gas inlet of the FIREBOY making sure it
audibly clicks into position. Check correct
positioning by pulling on the tubing.
5. Close all valves at the pressure regulator of the Gas Cartridge
Adapter.
Mounting the gas cartridge to the Gas Cartridge Adapter CP250
(Part No. 144051)
1. Read the user instruction on the gas cartridge before you connect the gas
cartridge to the adapter.
2. Place Gas Cartridge Adapter with
the gas cartridge in HORIZONTAL
(work bench) or VERTICAL (wall
mount) position. Do not move it
freely around. The Gas Cartridge
Adapter must be kept at a distance
of minimum 0.5 m from the
FIREBOY or any other heat source.
3. Open valve at the pressure regulator of the Gas Cartridge Adapter.
Don't open the valves before the tubing is connected to the FIREBOY
according to instructions.
4. Turn on the FIREBOY as described in the FIREBOY operating instructions.
144959_V04_OI_Cartridge_Adapters.doc
HORIZONTAL
3
OTHER
VERTICAL
