Seite 1
All manuals and user guides at all-guides.com QUALITY FOR LIFE INFORMATION I MANUALS I SERVICE BC 1000 E Betriebsanleitung 440 102_a I 01/2013...
Seite 2
All manuals and user guides at all-guides.com...
Seite 3
All manuals and user guides at all-guides.com 440 102_a...
All manuals and user guides at all-guides.com Zu diesem Handbuch Produktübersicht Lesen Sie diese Dokumentation vor der Inbetriebnah- Die Produktübersicht Bild 1 gibt einen Überblick über das me durch. Dies ist Voraussetzung für sicheres Arbeiten Gerät. und störungsfreie Handhabung. Elektromotor Beachten Sie die Sicherheits- und Warnhinweise in dieser Dokumentation und auf dem Gerät.
All manuals and user guides at all-guides.com Sicherheitshinweise Achtung! Das Gerät darf nicht im gewerblichen Einsatz Achtung! betrieben werden! Die Rotation des Schneidwerkzeugs dauert nach Bedeutung der Symbole am Gerät dem Abschalten des Motors noch an! Netz- und Verlängerungsleitungen vor dem Gebrauch Achtung! auf Anzeichen von Beschädigungen oder Alterung überprüfen.
All manuals and user guides at all-guides.com Kontrollieren Sie vor jeder Inbetriebnahme den Gerät nur in technisch einwandfreiem Zustand benut- zen. Zustand ihres Verlängerungskabels. Schutzschild, Fadenkopf und Motor immer frei von Mährückständen halten. ren. Körper und Kleidung vom Schneidwerk fernhalten. Gerät nicht Nässe oder Feuchtigkeit aussetzen.
All manuals and user guides at all-guides.com 3. Fadenkopf festhalten und mit dem Handschlüssel (3) Bedienung festziehen. Gerät einschalten, bevor Sie sich dem zu schneiden- den Gras nähern. Inbetriebnahme vorgehen. ACHTUNG! Gerät nach rechts und links schwenken, um das Gras Vor Inbetriebnahme immer eine Sichtkontrolle zu schneiden.
Seite 8
All manuals and user guides at all-guides.com Trimmen an Zäunen und Fundamenten Gerät nicht Nässe oder Feuchtigkeit aussetzen. Gerät in regelmäßigen Zeitabständen auf ordnungsge- ACHTUNG! mäßen Zustand überprüfen. Feste Bauten nicht berühren - Rückschlaggefahr! Keine Reinigungs- bzw. Lösungsmittel verwenden. Das Gerät kann damit irreparabel beschädigt werden.
All manuals and user guides at all-guides.com 2. Fadenmesser in einem Schraubstock befestigen und Die angegebenen Werte sind nach einem genorm- mit einer Flachfeile schärfen. ten Prüfverfahren ermittelt worden und können Nur in eine Richtung feilen! verwendet werden, um verschiedene Elektrowerk- zeuge miteinander zu vergleichen.
All manuals and user guides at all-guides.com Hilfe bei Störungen STÖRUNG MÖGLICHE URSACHE LÖSUNG Motor läuft nicht Motorschutzschalter hat abgeschaltet. Warten, bis der Motorschutzschalter Keine Netzspannung vorhanden den Trimmer wieder einschaltet. Si- cherungen / FI-Schutzschalter prüfen, Stromversorgung von Elektrofachkraft prüfen lassen. Verlängerungskabel prüfen, wenn nötig neues verwenden Elektrosense vibriert...
Ichenhauser Str. 14 Ichenhauser Str. 14 Seriennummer 89359 KOETZ 89359 KOETZ G 181 1815 EG-Richtlinien Harmonisierte Normen 2006/42/EG EN 60335-1 BC 1000 E 2004/108/EG EN 60335-2-91 2000/14/EG + 2005/88/EG EN ISO 3744 2006/95/EC EN 55014-1 2011/65/EU EN 55014-2 EN 61000-3-2...
All manuals and user guides at all-guides.com Product overview About this manual The product overview Fig. 1 provides an overview of the Please read this document before starting to use the machine. machine. This is essential for safe working and trouble- free handling.
All manuals and user guides at all-guides.com Safety notes neither is it intended to be used by people lacking supervised by someone who is responsible for Important! safety, or receive instructions from this supervisory The cutting tool continues to rotate even after the person in how to operate the tool.
All manuals and user guides at all-guides.com Assembly Keep your body and clothing away from the blade system. Important People who are not familiar with the trimmer should practice handling it while the motor is turned off. The machine is not allowed to be operated unless Wear appropriate working clothes.
Seite 15
All manuals and user guides at all-guides.com Starting the electric brushcutter Operation Switch on the machine before approaching the grass see Fig. 6. to be cut. walk forwards slowly. 3. Pass the carry strap over your left shoulder (Fig. 7) Sweep the machine to the right and left in order to cut and hook the strap into the eye on the top handlebar the grass.
All manuals and user guides at all-guides.com Trimming at fences and foundations Regularly check the machine is in good working order. IMPORTANT! Do not use any cleaning agents or solvents. They can cause irreparable damage to the machine. 1. Guide the machine slowly and carefully, without Cleaning the guard plate allowing the cutting line to strike against obstacles.
All manuals and user guides at all-guides.com Cleaning Important! The actual vibration values may differ from those Clean the machine carefully after each use in order to keep it functioning correctly. used for. Regularly clean all moving parts. Take measures to protect yourself against vibration loads.
All manuals and user guides at all-guides.com Help in case of malfunctions MALFUNCTION POSSIBLE CAUSE SOLUTION Motor does not run Motor protection switch has switched Wait until the motor protection off. switch switches the trimmer back on. No mains power Check the fuses / RCCB, have the electrical power supply checked by an electrician.
Ichenhauser Str. 14 Serial number 89359 KOETZ 89359 KOETZ G 181 1815 Type EC directives Harmonised standards 2006/42/EC EN 60335-1 BC 1000 E 2004/108/EC EN 60335-2-91 2000/14/EC + 2005/88/EC EN ISO 3744 2006/95/EC EN 55014-1 2011/65/EU EN 55014-2 EN 61000-3-2...
