DC Power Supply
To use the RDX2 Pro as a power supply, it can be connected to either an AC or DC power source. Output voltage
and current are selectable, with voltage at 5.0-25.0V and current at 0.1-14.0A. (130W Max.). The user can set
appropriate voltage and current based on the device you plan to power.
Warning
Note
Press the MODE/STOP button to exit any charging programs
you are currently in and then SCROLL to the DC POWER SUPPLY
program. Press the Jog Dial ENTER to enter the program. Press
the Jog Dial ENTER again and the Output Voltage will begin
to flash. SCROLL to adjust to the desired voltage (See Warning
above.) Once set, press ENTER to accept, and the Amperage
will flash. SCROLL to adjust to the desired Amperage for the
DC charger or other devices you are planning to power. After
selecting the setting, press and hold ENTER to activate the
power supply.
Once activated, the charger will display the following real-time
information: Output Voltage, Amp Draw, & POWER in Watts Out.
24
Note
WARNING: IF SELECTING A VOLTAGE OVER 12V, MAKE SURE THE DEVICE YOU
PLAN TO POWER CAN ACCEPT IT. APPLYING HIGHER VOLTAGE CAN DAMAGE OR
DESTROY A DEVICE NOT RATED TO OVER 12V.
NOTE: THE DC OUTPUT IS ONLY FOR TEMPORARY USAGE; WE DID TEST THE DC
OUTPUT TO POWER TIRE WARMERS, ENGINE WARMER, LED PIT LIGHT, MINI-
FAN, AND DC-POWERED SOLDERING IRON. BUT WE CAN NOT GUARANTEE IT
CAN WORK WELL ON ALL THE DC-POWERED ACCESSORIES IN THE MARKET.
NOTE: ONCE THE POWER SUPPLY IS ACTIVATED, YOU WILL NO LONGER BE
ABLE TO CHARGE ON THE OTHER PORT.
Shown here is an example of an engine head
heater used to warm a nitro engine.
BATT/PROGRAM
A
DC POWER SUPPLY
POWER SET
A
U=12.0V I=10.0A
POWER SET
A
U=12.0V I=10.0A
U=12.0V I=10.0A
A
POWER = 120W
*FLASHING
