Pb Lead-Acid Battery Program
Pb Lead-Acid Battery Program: This program is only suitable for charging Pb (Lead-Acid) batteries
with nominal voltage ranging from 2 to 20V, which are significantly different from NiMH/NiCd
batteries. Pb batteries are suggested to charge with a low current of 0.1C and cannot be used for fast
charging.
Selecting the Battery Type: After powering on the RDX2 Pro, press the MODE/STOP button and
SCROLL with the Jog Dial until you reach the Pb BATT program for the battery type you wish to charge.
Press the Jog Dial ENTER button to enter the Charge Mode menu.
Selecting the Charge Mode: The RDX2 Pro offers the following Pb charge modes: Normal, AGM, Cold
Mode, and Discharge.
PLEASE FOLLOW THE INSTRUCTIONS PROVIDED BY THE BATTERY MANUFACTURER.
Note
Pb Normal/ AGM Mode: These two modes program the
same. AGM mode is referred to below. After selecting the
correct battery type, turn the dial to change it to the 'AGM
CHARGE' mode. Press the ENTER button and the amp rate
value will begin flashing. Turn the dial to adjust the value to
the desired charge rate. The amp rate should be set to 1/10th
of capacity. For example, if you are charging a 15Ah battery,
the charge rate should be set to 1.5A. Follow the instructions
provided on your battery when setting the amp rate.
Press the ENTER button again and the nominal battery pack
voltage will begin flashing. Turn the dial to set the voltage
and the number of cells.
Press and hold the ENTER button for 3 seconds to start
charging.
Once charging has commenced, the charger will display the
following real-time information: battery type with cell count,
charging current, battery voltage, working mode, elapsed
time and charged capacity.
When charging is complete, the screen will read "END: FINISH"
and the charger will emit an audible "ring" sound. It will also
display the final voltage, and charged capacity.
22
BATT/PROGRAM
A
Pb BATT
Pb AGM CHG
A
1.5A 12.0V(6P)
*FLASHING
Pb AGM CHG
A
1.5A 12.0V(6P)
Pb AGM CHG
A
1.5A 12.0V(6P)
BATTERY CHECK
A
.............
P-6 1.5A 13.56V
A
CHG 002:22 00106
[END: FINISH]
A
13.56V 14260mAh
[TIME:04:45:32]
A
13.56V 14260mAh
