Settings – User interface
Figure 1
Figure 2
Option pages at a glance
Nr Information / Input option
1 Shows the water temperature in °C.
POWER IN: Shows the instantaneous power consumption of the boiler.
2
VOLTAGE: Shows the current supply voltage of the boiler.
3 USED PV ENERGY: Displays the total PV energy consumed by the boiler.
CHANGE MIN. TEMPERATURE: With the
4
This option interface is not available in all operating modes (see operating modes).
5
CHANGE SYSTEM MODE: You can use the
6 Shows the boiler type and the version numbers of the electronics and software.
Briefly pressing the
page (see figure 1).
A long press turns the boiler on or off.
To change possible settings on an option page, such as
the minimum temperature or the operating mode, briefly
press the button (see figure 2).
button you can change the minimum temperature.
button to change the operating mode.
8
button takes you to the next option
