extsensor {port_num} {sen_type} {sen_field}
publish delta show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port set {port_num}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port show
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state set {OFF=0|ON=1|
DISABLED=2}
extsensor {port_num} {sen_type} {sen_field}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state show
extsensor period set {24H=0|12H=1|2H=2|1H=3|
30MIN=4}
extsensor period show
gsm
gsm enabled set {OFF=0|ON=1}
gsm enabled show
gsm pin set "{pin_num}"
gsm pin show
gsm phonenum set "{phone_num}"
gsm phonenum show
gsm admin sms set "{phone_num}"
gsm admin sms show
gsm admin sms enabled set {OFF=0|ON=1}
gsm admin sms enabled show
gsm admin email enabled set {OFF=0|ON=1}
gsm admin email enabled show
gsm admin email set "{email_addr}"
gsm admin email show
gsm dtmf sms pin enabled set {OFF=0|ON=1}
gsm dtmf sms pin enabled show
gsm dtmf sms master pin set "{pin_num}"
gsm dtmf sms master pin show
gsm phonebook check set {OFF=0|ON=1}
gsm phonebook check show
gsm freecall enabled set {OFF=0|ON=1}
gsm freecall enabled show
gsm admin only set {OFF=0|ON=1}
gsm admin only show
gsm sms response set {OFF=0|ON=1}
gsm sms response show
gsm sms error set {OFF=0|ON=1}
gsm sms error show
gsm sms signal set {OFF=0|ON=1}
gsm sms signal show
gsm port name set {OFF=0|ON=1}
gsm port name show
gsm sms autosync set {OFF=0|ON=1}
gsm sms autosync show
gsm call voice enabled set {OFF=0|ON=1}
gsm call voice enabled show
gsm call dtmf enabled set {OFF=0|ON=1}
gsm call dtmf enabled show
103
Expert Power Control 1202/1292
show s publish delta value
sets Port for Pow er Port Sw itching actions
show s Port for Pow er Port Sw itching actions
sets Port state for Pow er Port Sw itching actions
show s Port state for Pow er Port Sw itching
actions
sets sensor Min/Max measurement period
show s sensor Min/Max measurement period
enters cmd group "gsm"
activates the built-in GSM module
show s if the built-in GSM module is enabled
sets PIN and sw itches the PIN request on
show s the PIN of the SIM card
sets the phone number of the SIM card
show s the phone number of the SIM card
sets phone number for SMS status changes
show s phone number for SMS status changes
enables status changes sent via SMS
show s if status changes via SMS are enabled
enables status changes sent via email
show s if status changes via email are enabled
sets status email recipient address
show s status email recipient address
enables necessary pin for port changes
show s if pin is needed for port changes
sets master pin for port changes
show s master pin for port changes
only allow access to calls that correspond to
phonebook entries
show s if phonebook change enabled
enable functions associated w ith incoming phone
numbers
show if freecall enabled
only allow caller actions from the admin
phonenum
show if caller actions limited to admin phoennum
send a SMS respone for every SMS cmd
show if a SMS respone is sent for every SMS
cmd
send a error SMS for a defective incoming SMS
show if error SMS are sent for defective
incoming SMS
send status messages w hen signal quality
changes
show s if status messages are sent for signal
quality changes
enable that complete port names are sent via SMS
show if complete port names are sent
get date and time from GSM after pow er-up
show if autosync is enabled
enable voice samples w hen a call is coming in
show if voice samples are enabled
allow DTMF tones in voice steering
show if DTM tones are enabled
6
6
6
6
© 2022 GUDE Systems GmbH
