5.2.2.3.2 Connection with pre-shared key (PSK)

In addition to a WPS connection, you can also establish
a connection using a Pre-Shared-Key. The required key is
often on the rear of the router, or you may have defined it
yourself. This method is used automatically for networks
without WPS. You can call up the Pre-Shared-Key function
on networks with WPS by selecting menu item "Skip
WPS". An input field should now appear. You can enter the
required key (PSK) by turning the navigation controller and
pressing the [ENTER] button. If you should select the wrong
character, you can navigate to item "BKSP" and press the
[ENTER] button. The last character is deleted from the input
field. Navigate to "OK" and press the [ENTER] button to
complete the entry. The radio should now establish the
connection to the network.

5.2.2.3.3 Using an open network

If you plan to use an open network (not recommended),
you just have to select the network ID from the list of
available networks and confirm by pressing [ENTER]. The
radio then connects immediately to the network.

5.2.2.3.4 Wired connection

If you wish to establish a connection via a network cable
(RJ45/LAN), you just have to connect the radio with the
network cable and select the [[Wired]] option, before
confirming by pressing [ENTER]. The radio now connects
automatically to the network.

5.2.2.3.5 Manual configuration

If you are unable to find your WLAN network with the
assistant or if problems occur during connection, you can
try to configure the network connection manually. This is
also necessary if your router/AccessPoint does not support
automatic assignment of IP addresses (DHCP disable).
After the scan process completes select [Manual config]
menu item to start configuration.
Option 1:
Wired > [ENTER] button
DHCP enable > [ENTER] button
The radio tries to obtain an IP from the router and
connect to the network.
Option 2:
Wired > [ENTER] button
DHCP disable > [ENTER] button
Note
You have to enter the entire network configuration (IP
address, Subnet mask, Gateway address, DNS) in the
following screens. You can select the individual digits
by turning the navigation controller and pressing the
[ENTER] button. Refer to the configuration of your own
network for the network information required, or request
this information from your network administrator. Once
all the data required has been entered, the radio will
then try to connect to the network.
Option 3:
Wireless > [ENTER]-button
DHCP enable > [ENTER]-button
SSID > Enter SSID
If you have a hidden or an undetectable WLAN network
you must enter the required network ID (SSID) by turning
and pressing [ENTER] and confirming with ‚OK'.
After entering the network ID you are prompted to select
the encryption method. Depending on your network
configuration, select one of the following options:
Open > [ENTER] button> (No key)
Or
Pre-Shared Key > [ENTER] button> (not activated/WEP)
Or
WPA > [ENTER] button> (TKIP/AES)
Or
WPA2 > [ENTER] button> (TKIP/AES)
Note
For the methods with PSK, WPA and WPA2, you must
subsequently enter the required network key in the input
field by turning the navigation controller and pressing
the [ENTER] button, and then confirming your entry with
"OK".
The radio will then try to establish a connection (SSID,
encryption and key depend on the configuration of your
access point).
Option 4:
Wireless > [ENTER] button
DHCP enable > [ENTER] button
13
