In case that HD-SDI Inputs are not supported in Monitor, please use HD-SDI Conver-
ter to connect HD-SDI cable with Monitor.
VIDEO SUB-OUT
connector
Technical specifications
Protection rating (IP / IK):
Temperature range (operation):
Power consumption:
Dimensions:
Weight:
16
IP67
-20°C ~ +50°C
10.5 max.
76mm x 70mm x 218mm
0.94kg
HD-SDI CABLE
AC24V/GND
(Black wire)
AC24V/DC12V
(Red wire)
RS485+ (White wire)
RS485- (Grey wire)
Joystick
LED
ON/OFF
Switch
