Setting up the network on the computer
You must now make certain network settings so that the PC can work with the router. First, configure the
TCP/IP settings of the PC which you have connected to the router.
The actual procedure will vary slightly according to your operating system. An example for Windows
is described below.
Select Start – Einstellungen – Systemsteuerung.
Click on Netzwerkverbindungen.
Double click on the LAN connection with which you are connected to the router.
Click on Eigenschaften.
Select Internetprotokoll (TCP/IP) and click on Eigenschaften again.
If the IP-Adresse automatisch beziehen and DNS-Serveradresse automatisch beziehen options have
already been activated, your computer is already configured for DHCP. Click on Abbrechen and close
the next windows with OK. You do not have to restart your network.
If the IP-Adresse automatisch beziehen and DNS-Serveradresse automatisch beziehen options have
not been activated, activate them now and click on OK. Close the following screens. Restart the network.
Restarting the network
To restart the Sinus 154 DSL Basic SE, switch it off and then back on again with the Power button at the
rear of the unit.
Ensure that the Power and T-DSL indicators at the front of the unit are on continuously.
Reboot your PC.
You have now configured and opened a link between your PC and the Sinus 154 DSL Basic SE.
®
