The Turbo Fan (if available)
Do not block the air inlet and outlet
openings when storing food, otherwise air
circulation provided by the turbo fan will be
impaired.

3.3 Accessories

3.3.1 Ice Tray

• Fill the ice tray with water and place in
the freezer compartment.
• After the water has completely frozen,
you can twist the tray as shown below to
remove the ice cubes.

3.3.2 The Fresh Dial (In some models)

Fresh dial
If the crisper is full, the fresh dial located
in front of the crisper should be opened.
This allows the air in the crisper and the
humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.
Turbo fan

3.3.3 The Freezer Box

The freezer box allows food to be accessed
more easily.
Freezer upper cover
Removing the freezer box:
• Pull the box out as far as possible
• Pull the front of the box up and out
Carry out the opposite of this operation
when refitting the sliding compartment.
Always keep hold of the handle of the
box while removing it.
Visual and text descriptions in
the accessories section may vary
according to the model of your
EN - 32
Freezer boxes
or
Freezer boxes
appliance.
