HD 8CH I/O
HD 8CH I/O
HD 8CH I/O
HD 8CH I/O
HD 8CH I/O
1
Parallel Port
2
RJ-45 Port
3
Side Speaker (Gray)
4
Rear Speaker (Black)
5
Central / Bass (Orange)
6
Line In (Light Blue)
*
7
Front Speaker (Lime)
*
If you use 2-channel speaker, please connect the speaker's plug into "Front Speaker Jack". See
the table below for connection details in accordance with the type of speaker you use.
TABLE for Audio Output Connection
Audio Output Channels Front Speaker Rear Speaker
(No. 7)
2
4
6
8
ASRock
manuals search engine
8
Microphone (Pink)
9
USB 2.0 Ports (USB01)
10
USB 2.0 Ports (USB23)
11
VGA Port
12
PS/2 Keyboard Port (Purple)
13
PS/2 Mouse Port (Green)
Central / Bass
(No. 4)
(No. 5)
V
--
--
V
V
--
V
V
V
V
V
V
K8NF6P-VSTA
Motherboard
Side Speaker
(No. 3)
--
--
--
V
3 3 3 3 3
