Technical Data; What To Do If - Becker Centronic SensorControl SC811 Montage- Und Betriebsanleitung

Rated voltage
Degree of protection
Permissible ambient temperature
Maximum emitted transmission out-
put
Radio frequency
The maximum transmitter range on and in the building is up to 25 m, and up to
350 m in the open.
Problem
The drive is not functioning.
The transmission pilot light on the
sensor lights up.
Automatic drive commands are not
executed.
System does not extend automatic-
ally when slide switch is set to " ".
System does not extend manually
when slide switch is set to " " or " ".
System extends when it is raining
despite rain sensor.
20 - en

Technical data

230-240 V AC / 50-60 Hz
IP 44
-25 to +55°C
≤ 25 mW
868.3 MHz

What to do if...?

Reduce the distance from the re-
ceiver.
Program the sensor in the receiver.
Set the slide switch of the hand-held/
wall transmitter to " ".
Wait until the rain sensor has dried.
Adjust the sun threshold on the
sensor.
Wait for the wind to die down.
Wait for the wind to die down.
Check connection.
Remedy
