4-Mark and trace the perime-
ters of the inside and marginal
elements of the working area
that obstruct the correct func-
tioning of the robot.
Important
The figure represents an exam-
ple of inside an marginal ele-
ments of the working area and
the distances that must be re-
spected for the tracing of the un-
derground
GB
perimeter wire.
Mark and trace the perimeters
of all the elements in iron or in
other metals (manholes, electric
connections, etc.) to avoid inter-
ferences to the signal of the pe-
rimeter wire.
Do not mark those obstacles
(trees, poles, etc.) that do not
hamper the normal functioning
of the robot.
laying of the
bed
protruding roots
pool
tree
- 16 -
manhole
hedge
wall
shower dish
IDM - 41501711400.tif IDM - 41501601100.tif
pole
IDM - 41501701000.tif
