Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
To make removal easier, a flat,
pointed object such as a slotted
screwdriver can be used.
Release the wiring and remove the
existing switch if necessary.
On-off circuit: Connect the conductor
to the lamp/luminaire at connecting
terminal 2.
Two-way circuit: Connect the two
corresponding supply cables to the
two-way switch at connecting termi-
nals 1 and 2.
Intermediate switch circuit: Connect
the two corresponding supply cables
to the intermediate switch at connec-
ting terminals 1 and 2.
Connect the phase conductor to con-
necting terminal L.
Connect the neutral conductor to con-
necting terminal N.
Connect the neutral conductor of the
lamp / luminaire to the neutral con-
ductor of the house installation.
