15mm through axle for FOX, DT-Swiss & Rock Shox suspension forks
Attention! Please carefully read the entire user manual before using the quick release through axle.
We congratulate you on the purchase of your new TUNE product. You have made a good choice. TUNE products are designed and manufactured in
Germany according to highest quality standards. Nevertheless, it is necessary to follow following advice and service the product according to this user
manual. Please make any other users familiarise themselves with this manual.
Technical specifications:
Material axle: aluminium 7075 CNC machined
Material lever: carbon
Weight: approx.. 43g
DC15 FX (for Fox forks)
thread: M14 x 1,5
axle length: 136,5mm
compatible with following fork models:
-suitable for all QR15 model forks
The DC15 is not compatible with following fork models:
This list does not claim to be complete! Changes by the fork manufacturers are possible at any time in which case the DC15 may no
longer be compatible.
WARNING! Before every ride, ensure that the QR axle is assembled and properly closed/fastened as outlined in this
manual. An incorrect installation or adjustment can lead to serious or fatal injuries.
Please carefully read the owner's manual of the respective fork manufacturer regarding changes to the fork.
Assembly:
1.
Place the front wheel (without DC15 thru axle) in the drop-outs under your suspension fork's lower legs. Position the brake rotor
between the brake pads while carefully inserting the front wheel hub parallel into the opening of the drop-outs.
Tipp:
Dirt and grit can accumulate between the drop outs. Always check and clean this area before inserting the
front wheel.
2.
Grease the axle and thread of your DC15 thru axle. Insert the axle through the drop outs of your fork and insert fully until the axle's
thread contacts the fork leg's thread.
3.
Insert the axle approx. 6 revolutions into the fork, but not all the way as far as it goes! Then, flip the lever to create some tension. In
the closed position, the lever should be pointing upwards and close to the forks lower leg, so that it cannot easily be damaged by
contact or open up by itself.
3.1 If the lever position is not optimal, it can be corrected. To do this, turn the axle out again, and change the position of the
lever, by pushing the lever against the spring until the position can be readjusted. This is felt by engaging every 60°.
3.2 Never try to turn the DC15 thru axle with a large force. Even if the required clamping force cannot be reached or the
thru axle does not seem to want to go into the drop outs, never apply a large amount of force. This can damage the
DC15!
TUNE DC 15 Through-Axle
User manual
Current as of May 2012
DC15 RS (for RockShox / SRAM forks)
thread: M15 x 1,5
axle length: 141mm
-Rock Shox Sektor R / RL / TK
-Revelation RL / RLT / RLT Ti / World Cup / XX /
XX World Cup
-SID RLT / RLT Ti / World Cup / XX World Cup
-Niner RDO
DC15 DT (for DT Swiss forks)
thread: M15 x 1,5
axle length: 131,5mm
-XMM 15mm Thru axle
-120 Twin Shot 15mm / tapered
-140 Twin Shot / tapered
-EXM 150 15mm / tapered
-EXC 150
- XMM 29 Thru Bolt 100/120
