• Children should be supervised to ensure that they
do not play with the appliance. If the supply cord
is damaged, it must be replaced by the manufac-
turer, its service agent or similarly qualified per-
sons in order to avoid a hazard.
Regulation (EU) No 517/2014 of the European
Parliament and of the Council
• Non-hermetically sealed equipment charged with
fluorinated greenhouse gases shall only be sold
to the end user where evidence is provided that
the installation is to be carried out by an undertak-
ing certified in accordance with Article 10.
• Equipment pursuant to Article 11(5) of Regulation
(EU) No 517/2014 may only be sold to final con-
sumers who can prove to the seller in writing that
the installation of the equipment is being carried
out by a company that has a company certificate
pursuant to Article 6(1).

Names of Parts

Indoor Unit
► P. 3, item 1
1. Front panel
2. Air filter
3. Optional filter (if installed)
No. Led
1 SLEEP
2 Temperature display (if present)/Error
code
3 TIMER
Note: The shape and position of switches
and indicators may be different according to
the model, but their function is the same.
Emergency Function & Auto-restart
Function
Auto-restart Function
The appliance is preset auto – restart function by
manufacturer. In case of a sudden power failure, the
module memorizes the setting conditions before the
power failure. when the power restores, the unit
restarts automatically with all the previous settings
preserved by the memory function.
To deactivate the AUTO-RESTART function, pro-
ceed as follows:
– Switch the air conditioner off.
– Press the emergency button.
– Keep pressing the emergency button for more
than 10 seconds until you hear four short beeps
from the unit. The AUTO-RESTART function is
deactivate.
• To activate the AUTO-RESTART function, follow
the same procedure until you hear three short
beeps from the unit.

Remote Controller

No. Buttor
1 [▼] (TEMP DN)
2 [▲] (TEMP UP)
4. LED Display
5. Signal receiver
6. Terminal block cover
7. Ionizer generator (if installed)
8. Deflectors
9. Emergency button
10. Indoor unit rating label (Stick position optional)
11. Airflow direction louver
12. Remote controller
Outdoor Unit
► P. 4, item 2
13. Air outlet grille
14. Outdoor unit rating label
15. Terminal block cover
16. gas valve
17. liquid valve

Indoor Unit Display

► P. 4, item 3
[ ]
[ ]
[ ]
Emergency Function
If the remote controller fails to work or maintenance
necessary, proceed as follows:
– Open and lift the front panel up to an angleto
– One press of the emergency button (one beep)
– Two press of the emergency button within 3 sec
– To switch off the unit, you just need to press the
► P. 4, item 4
1. front panel
2. Emergency button
The emergency button in some models could be on
the right part of the unit under the front panel.
Function
Press it to decrease temperature/time setting.
Press it to increase temperature/time setting.
Note: the above figures are only intended to
be a simple diagram of the appliance and
may not correspond to the appearance of the
units that have been purchased.
Function
SLEEP mode
Lights up during Timer operation when the air
conditioner is operational
Displays the malfunction code when fault occurs.
Lights up during Timer operation.
reach the emergency button.
will lead to the forced COOLING operation
(two beeps) will lead to the forced HEATING oper-
ation.
button again (a single long beep).
Note: The shape and position of the emer-
gency button may be different according to
the model, but their function is the same.
Note: the external static pressure of heat
pumps is 0 Pa for all models.
