INTRODUCTION

The PC Card Slot

The computer is equipped with two PC card slots. These are PCMCIA 3.3V/ 5V/
12V sockets, type II x2 or type III x1.Type III PC cards only fit into the lower
socket.
Align the PC card with the slot and
push the card in until it locks into
place.
.
To remove a PC card, simply press
the eject button next to the slot.
Figure 16
SD- Media and Memory Sticks
The Memory Stick and the Secure Digital
Media should be inserted until it 'clicks"
into place.
They will appear as a Removable Disk
when you double-click the My Computer
Figure 17
(icon) on your desktop in Windows.
They may be removed by pressing your
finger against them to eject. Be careful not
to do this while information is being written
to, or read from the or you could lose data.
Figure 18
58
