6 Switch on/off Seasonal Flow Control (SFC).
• The SFC function optimizes the pump speed and with it the water volume and pumping head
based on the water temperature.
7 Control system connection
• The control unit OASE Eco Control (accessories) is required to operate the pump.
• Alternatively, the pump can be integrated in a OASE Control network.
Hose sleeve ∅ 50 mm
• For information on OASE Control, visit www.oase.com.
Hose sleeve ∅ 38 mm
8
9
• Alternative for outlet AquaMax Eco Expert 21000 and 26000.
10 Hose clips for fastening hoses on the hose sleeves.

Installation variants

 A
• Variant (a): Submerged installation of the pump
– The pump is positioned in the pond.
– Water is drawn in via the filter cage (pond bottom filtration).
• Variant (b): Dry installation of the pump
– The pump is installed without a filter cage outside the pond but lower than the water level.
– Water is drawn in via a satellite filter or skimmer.

Installation and connection

The pump can be installed submerged (in water) or dry (outside the water).
The use of the pump is only permitted subject to adherence to the specified water quality.
• Pool water or salt water can impair the appearance of the unit. Such impairments are excluded
from the warranty.
WARNING
Severe injuries or death from operation of the unit in a swimming pond. Faulty electric compo-
nents will apply dangerous electric voltage to the water.
 Never operate the unit in a swimming pond.
