The USB connection
See page 49 for a more detailed description of the USB front connector.

The line-in connector

The line-in connector located behind the magnetic cover at the front of the BB-200 processes electrical
high-level audio signals in analogue form. This connector is suitable for all external devices with analogue
audio output, like media players, iPod®, smartphones etc. (connection over headphone output). For the
connection, please consult the operating instruction of the external device. A suitable 3.5 mm cable is
available in the accessory shop
The headphone connection
The headphone jack of the BB-200, located behind the magnetic cover on the front, allows you to connect
a commercially available headphone with 6.3 mm jack plug. A 3.5 mm jack adapter for smaller headphones
can be obtained from the accessory shop.
55
