Place the second drum, now half full, on the floor on the right-
hand side of the first drum (item 3 illustration 2). Insert the
second group of hoses containing a white hose into this drum
(item 5 illustration 2). Make sure that the hoses are properly
led into the drum all the way down to the bottom, and that the
opening is well sealed by the tapered plug.
The solvent system is now filled-up on the left side of the unit.
Both drums should be half full. The left-hand drum, contains
the solvent that will be re-circulating for the automatic wash
cycle, and the right-hand drum contains clean solvent for rins-
ing. The contents of the right drum will gradually be used up
and transferred to the left drum.
Now the solvent fill-up procedure
repeat
the unit.
Operating instructions
Operating instructions should be formulated on the basis of
this manual and translated into the language spoken by the
employees. It should always be available close to the machine.
To avoid confusion, the employees must be informed about the
solvent currently being used in the machine.
OPERATING INSTRUCTIONS
The following procedure is valid for either side of the unit:
Empty the spray-gun of any residual paint into a separate spills-
dish.
Open the main valve for compressed air (item 7 illustration 1).
Open the lid for the automatic washer (make sure it `clicks` into
the full open position).
Place the spray-gun inside (see illustration 5).
Be sure to fit the trigger clip following illustration 6, and to
push the spray-gun up against the nozzle for the paint–channel
(item 1 illustration 5) before you lock it into position with aid of
the magnets of the trigger clip.
If you prior to cleaning prefer to remove the Air-cap and the
needle of the spray-gun, then place those items as shown by
arrow 5 in illustration 5.
Close the lid, and start the automatic prewash cycle by pressing
the foot pedal No.8 in illustration 1. The spray–gun will now be
automatically cleaned for approx. 1.5 minutes with circulating
solvent.
When the automatic prewash cycle is completed, the spray-gun
can be rinsed with clean solvent. The rinsing pump is activated
by pressing the foot pedal No. 9 in illustration 1, and contin-
ues to work for as long as the pedal is depressed. The pump
will feed approx. 75 cc of solvent per pump stroke. 2–3 pump
strokes are generally sufficient for one rinse. Less if the solvent
has recently been changed.
16014 rev 2022-02-01
When the cleaning procedure is completed, the lid can be
opened and the spray-gun taken out. It can now be manually
further washed or rinsed if required.
By pressing foot pedal No.10 in illustration 1 (NOTE: press it all
the way down !), re-circulating solvent will be fed through the
brush placed in the sink (item 1 illustration 7).
By pressing foot pedal No.11 in illustration 1, clean solvent
will be fed through the spray-nozzle placed in the sink (item 2
illustration 7).
The brush and spray-nozzle in the sink can be used indepen-
dently of the automatic washer at any time, provided that the
lid for the automatic washer is closed. The intensity of the spray
can be adjusted with the air–flow restrictor (item 1 illustration
of 14).
for the right side
Connect the spray-gun to the air–line on the left side of the
machine (item 4 illustration 1), and blow out the spray–gun
through the funnel in the sink (item 3 illustration 7). By using
this funnel, you prevent the fumes from spreading within the
premises.
Finally, the spray-gun can be blown dry by using the air–gun on
the right side of the unit (item 12 illustration 1).
Close the lid after cleaning.

SERVICE

Weekly:
– Remove the strainers at the bottom of each automatic
Monthly:
– Remove the five nozzles in each automatic washer and
When changing drums:
– Check and if necessary clean the strainer on the suction
washer (item 2 illustration 5) and clean them,
get to re-fit !
clean them with clean solvent. (see illustration 8).
hose for circulating solvent.
do not for-
