A-7. Black mark specifications

Reverse side of paper 30~300 mm 15 mm or more
5 ± 1 mm
Printing direction
Make the PCS value of the black marks 0.90 or more.
Note The printing start accuracy, based on detection of the black marks, is
± 2 mm with respect with the standard printing area. For the printing
length, taking into account the initial surrounding air temperature and
the deviation in platen diameters during manufacturing, the accuracy
is ± 2% with respect to the settings values. Taking into account the
working life of the printer, during printing layout be sure to allow for
a maximum error of -5% with respect to the settings values, when using
preprinted paper.
– 83 –
